AK100/3DS-5.0-V-GREY - NYÁK-os sorkapocs 3-pólusú RM=5,0mm szürke - PTR MESSTECHNIK
0.5469 €+ VAT
0.6946 € incl. VAT
0.6946 € incl. VAT
AK100/3DS-5.0-V-GREY - NYÁK-os sorkapocs 3-pólusú RM=5,0mm szürke - PTR MESSTECHNIK
The picture is for illustration purposes only. Please read the product description!
In stock 498 pcs
0.5469 €+ VAT
0.6946 € incl. VAT
0.6946 € incl. VAT
Terminal Block, for PCB 3-pole RM=5,0mm Grey
Manufacturer code:
AK100/3DS-5.0-V-GREY
Manufacturer:
Datasheet:
Group:
Terminal Blocks - PCB Mount
Component Family:
Product Range:
Case:
Termination Type:
Through-hole technology
Insulation Voltage [V], Max.:
2 kV
Standard:
VDE, UL
Continual Current [A], Max.:
24 A
Connector Type:
Solderable, terminal block
Voltage [V], Max.:
250 V
Cable Diameter [mm], Max:
2.5 mm²
Cable Diameter [mm], Min.:
0.2 mm²
Contact Material:
Brass-/steel-plate
Insulator Material:
PA 66
Operating Temperature Min. [°C]:
-30 °C
Operating Temperature Max. [°C]:
+105 °C
ROHS:
Yes
Connector Configuration:
pcs
Quantity discount:
Quantity [pcs]
Net price [EUR]
Gross [EUR]
200
0,34 €
0,43 €
Our Warehouse
498 pcs
Available for immediate delivery
Our Shop in Szeged
0 pcs
In Stock (or in 2 days from our warehouse the available quantity)
Package deals
Customers also bought this
Data
Additional Datasheet:
Weight:
3.44 g/pcs
