AK100/4DS-5.0-H-GREY - 90° NYÁK-os sorkapocs 4-pólusú RM=5.0mm Fektetett szürke - PTR MESSTECHNIK

0.575 €+ VAT
0.7302 € incl. VAT

AK100/4DS-5.0-H-GREY - 90° NYÁK-os sorkapocs 4-pólusú RM=5.0mm Fektetett szürke - PTR MESSTECHNIK

Name: AK100/4DS-5.0-H-GREY - 90° NYÁK-os sorkapocs 4-pólusú RM=5.0mm Fektetett szürke - PTR MESSTECHNIK
Brand: PTR MESSTECHNIK
SKU: 53-26-64
Price: 0.7302 EUR
Availability: InStock

The picture is for illustration purposes only. Please read the product description!

In stock 47 pcs

0.575 €+ VAT
0.7302 € incl. VAT

Terminal Block, 90° for PCB 4-pole RM=5.0mm Right Angle Grey

Manufacturer code:

AK100/4DS-5.0-H-GREY

Manufacturer:

PTR MESSTECHNIK

Datasheet:

PTR_AK100_..DS-5.0-H-GREY.pdf

Group:

Terminal Blocks - PCB Mount

Component Family:

Terminal block, RM=5.0mm

Product Range:

AK100

Case:

PCB-mountable

Termination Type:

Through-hole technology

Insulation Voltage [V], Max.:

2 kV

Standard:

VDE, UL

Continual Current [A], Max.:

24 A

Connector Type:

Solderable, terminal block

Voltage [V], Max.:

250 V

Cable Diameter [mm], Max:

2.5 mm²

Cable Diameter [mm], Min.:

0.2 mm²

Contact Material:

Brass-/steel-plate

Insulator Material:

PA 66

Operating Temperature Min. [°C]:

-30 °C

Operating Temperature Max. [°C]:

+105 °C

ROHS:

Yes

Number of Pins:

Raster measure:

5 mm

10 mm

Connector Configuration:

1-row, axial, upper wire

1-row, radial, side wire

pcs

Quantity discount:

Quantity [pcs]

Net price [EUR]

Gross [EUR]

0,48 €

0,61 €

Our Warehouse

47 pcs

Available for immediate delivery

Our Shop in Szeged

0 pcs

In Stock (or in 2 days from our warehouse the available quantity)

Data

Additional Datasheet:

ROHS_PTR2.pdf

Weight:

4.85 g/pcs
