220 nF 1000/600V ±10% MKP-10 RM=27,5mm - WIMA - MKP1O132206B00KSSD

471.49 Ft+ VAT
598.79 Ft incl. VAT

220 nF 1000/600V ±10% MKP-10 RM=27,5mm - WIMA - MKP1O132206B00KSSD

Name: 220 nF 1000/600V ±10% MKP-10 RM=27,5mm - WIMA - MKP1O132206B00KSSD
Brand: WIMA
SKU: 11-06-46
Price: 598.79 HUF
Availability: InStock

The picture is for illustration purposes only. Please read the product description!

In stock 1102 pcs

471.49 Ft+ VAT
598.79 Ft incl. VAT

Film Capacitor 1000/600V ±10% MKP-10 RM11 (27.5mm)

Manufacturer code:

MKP1O132206B00KSSD

Manufacturer:

WIMA

Datasheet:

WIMA_MKP_10.pdf

Group:

Film Capacitors

Component Family:

WIMA film capacitor

Product Range:

MKP10

Capacitance [F]:

220nF

Case Style:

PCB-mountable

Case:

RM=27.5mm

Termination Type:

Through-hole technology

Voltage Rating [V]:

1000VDC/600VAC

Number of Pins:

Tolerance [ % ]:

±10 %

External Length [mm]:

31.5 mm

External Width [mm]:

11 mm

External Height [mm]:

21 mm

Raster measure:

27.5 mm

Dielectric Characteristic:

Metallised Polypropylen-foil

Operating Temperature Min. [°C]:

-55 °C

Operating Temperature Max. [°C]:

+100 °C

ROHS:

Yes

pcs

Quantity discount:

Quantity [pcs]

Net [HUF]

Gross [HUF]

353,54 Ft

449,00 Ft

Our Warehouse

1102 pcs

Available for immediate delivery

Info

Additional Datasheet:

ROHS_Wima.pdf

Weight:

8.8 g/pcs
