691216510003S - NYÁK-os sorkapocs 3-pólusú, RM=5.08mm zöld 13.8mm magas - WÜRTH
The picture is for illustration purposes only. Please read the product description!
Out of stock
Terminal Block, for PCB 3-pole, RM=5.08mm Green 13.8mm High
Manufacturer code:
691216510003S
Manufacturer:
Datasheet:
Group:
Terminal Blocks - PCB Mount
Component Family:
Product Range:
Case:
Termination Type:
Through-hole technology
Insulation Voltage [V], Max.:
4 kV
Raster measure:
5.08 mm
Standard:
VDE
Continual Current [A], Max.:
24 A
Connector Configuration:
1-row, radial, side wire
Connector Type:
Solderable, terminal block
Voltage [V], Max.:
250 V
Cable Diameter [mm], Max:
2.5 mm²
Cable Diameter [mm], Min.:
0.2 mm²
Contact Material:
Réz ötvözet
Contact Plating:
Tinned
Insulator Material:
PA
Operating Temperature Max. [°C]:
+110 °C
ROHS:
Yes
Package deals
Data
Weight:
4.5 g/pcs
