AK3001/5KD-5.0-PEBBLEGREY - karos NYÁK-os sorkapocs 45° 5-pólusú RM=5.0mm szorítónyelv, szürke - PTR MESSTECHNIK

1.028 €+ VAT
1.3055 € incl. VAT

AK3001/5KD-5.0-PEBBLEGREY - karos NYÁK-os sorkapocs 45° 5-pólusú RM=5.0mm szorítónyelv, szürke - PTR MESSTECHNIK

Name: AK3001/5KD-5.0-PEBBLEGREY - karos NYÁK-os sorkapocs 45° 5-pólusú RM=5.0mm szorítónyelv, szürke - PTR MESSTECHNIK
Brand: PTR MESSTECHNIK
SKU: 53-17-58
Price: 1.3055 EUR
Availability: InStock

The picture is for illustration purposes only. Please read the product description!

In stock 48 pcs

1.028 €+ VAT
1.3055 € incl. VAT

Terminal Block, Sprung for PCB 45° 5-pole RM=5.0mm Grey

Manufacturer code:

AK3001/5KD-5.0-PEBBLEGREY

Manufacturer:

PTR MESSTECHNIK

Datasheet:

PTR_AK3001_..KD-5.0-PEBBLE_GREY.pdf

Group:

Terminal Blocks - PCB Mount

Component Family:

Terminal block, RM=5.0mm

Product Range:

AK3001

Case:

PCB-mountable

Termination Type:

Through-hole technology

Insulation Voltage [V], Max.:

2 kV

Raster measure:

5 mm

Standard:

VDE, UL

Continual Current [A], Max.:

24 A

Connector Configuration:

1-row, radial, side wire 45°

Connector Type:

Solderable, terminal block

Voltage [V], Max.:

250 V

Cable Diameter [mm], Max:

2.5 mm²

Cable Diameter [mm], Min.:

0.14 mm²

Contact Material:

Steel plate

Insulator Material:

PA 66

Operating Temperature Min. [°C]:

-30 °C

Operating Temperature Max. [°C]:

+105 °C

ROHS:

Yes

Number of Pins:

pcs

Our Warehouse

48 pcs

Available for immediate delivery

Our Shop in Szeged

0 pcs

In Stock (or in 2 days from our warehouse the available quantity)

Data

Additional Datasheet:

RETKAT2012_L_036.pdf ROHS_PTR2.pdf

Weight:

4.76 g/pcs
