SOM040100 - szilárdtest-jelfogó, 60 Vdc / 40 A MOSFET-kimenet, 3.5-32 Vdc bemenet - CELDUC

88.6116 €+ VAT
112.5367 € incl. VAT

SOM040100 - szilárdtest-jelfogó, 60 Vdc / 40 A MOSFET-kimenet, 3.5-32 Vdc bemenet - CELDUC

Name: SOM040100 - szilárdtest-jelfogó, 60 Vdc / 40 A MOSFET-kimenet, 3.5-32 Vdc bemenet - CELDUC
Brand: CELDUC
SKU: 49-05-23
Price: 112.5367 EUR
Availability: InStock

The picture is for illustration purposes only. Please read the product description!

In stock 2 pcs

88.6116 €+ VAT
112.5367 € incl. VAT

Solid State Relay, 60 Vdc / 40 A MOSFET-output, 3.5-32 Vdc Input

Manufacturer code:

SOM040100

Manufacturer:

CELDUC

Datasheet:

FA_SOM040100.pdf

Group:

Solid State Relays - Other

Component Family:

Solis State Relay (SSR)

Case:

Module

Termination Type:

mountable

Number of Pins:

Dimension Parameters:

58.5 x 45 x 30 mm

Contact Configuration :

SPST

Input Type:

Switching Type:

Immediate switching

Switched Current, Max. [A]:

40 A

Switched Voltage, Max. [V]:

60 V DC

Switched Voltage, Min. [V]:

5 V DC

Output Type:

MOSFETs

Control Voltage [V], Max.:

32 V

Control Voltage [V], Min.:

3.5 V

Operating Temperature Min. [°C]:

-25 °C

Operating Temperature Max. [°C]:

+90 °C

ROHS:

Yes

pcs

Our Warehouse

2 pcs

Available for immediate delivery

Info

Weight:

80 g/pcs
