Q0,032768-JTX520-12,5-20-LF - 32.768KHz SMD JTX520 ±20ppm 5ppm/Év Cl=12,5pF 4.8x1.9x0.8mm kvarc - JAUCH

1.828 €+ VAT
2.3215 € incl. VAT

Q0,032768-JTX520-12,5-20-LF - 32.768KHz SMD JTX520 ±20ppm 5ppm/Év Cl=12,5pF 4.8x1.9x0.8mm kvarc - JAUCH

Name: Q0,032768-JTX520-12,5-20-LF - 32.768KHz SMD JTX520 ±20ppm 5ppm/Év Cl=12,5pF 4.8x1.9x0.8mm kvarc - JAUCH
Brand: JAUCH
SKU: 62-02-84
Price: 2.3215 EUR
Availability: InStock

The picture is for illustration purposes only. Please read the product description!

In stock 2029 pcs

1.828 €+ VAT
2.3215 € incl. VAT

Quartz Crystal, SMD JTX520 ±20ppm 5ppm/Year Cl=12,5pF 4.8x1.9x0.8mm

Manufacturer code:

Q0,032768-JTX520-12,5-20-LF

Manufacturer:

JAUCH

Datasheet:

JTX520-081211-41-72.pdf

Group:

Crystals

Component Family:

Crystal for RTC in SMD package

Product Range:

JTX520

Frequency [MHz]:

32.768 KHz

Case Style:

Surface Mount (SMD)

Case:

JTX520

Termination Type:

Surface mount (SMD)

Number of Pins:

External Length [mm]:

4.8 mm

External Width [mm]:

1.9 mm

External Height [mm]:

1 mm

Raster measure:

3 mm

Frequency Tolerance [ppm @ °C]:

± 20 ppm @ 25 °C

Load Capacitance [pF]:

12.5 pF

Operating Temperature Min. [°C]:

-20 °C

Operating Temperature Max. [°C]:

+70 °C

ROHS:

Yes

pcs

Quantity discount:

Quantity [pcs]

Net price [EUR]

Gross [EUR]

100

1,31 €

1,66 €

Our Warehouse

2028 pcs

Available for immediate delivery

Our Shop in Szeged

1 pcs

In Stock (or in 2 days from our warehouse the available quantity)

Data

Additional Datasheet:

RETKAT2012_D_004.pdf ROHS_Jauch.pdf
