3300 uF 63V 105°C ±20% Radial d=25x40mm - PANASONIC - ECOS1JA332CA
3.8444 €+ VAT
4.8824 € incl. VAT
4.8824 € incl. VAT
3300 uF 63V 105°C ±20% Radial d=25x40mm - PANASONIC - ECOS1JA332CA
The picture is for illustration purposes only. Please read the product description!
In stock 57 pcs
3.8444 €+ VAT
4.8824 € incl. VAT
4.8824 € incl. VAT
Electrolytic Capacitor 63V 105°C ±20% Radial d=25x40mm RM=10mm
Manufacturer code:
ECOS1JA332CA
Manufacturer:
Datasheet:
Group:
Electrolytic Capacitors
Component Family:
Product Range:
Capacitance [F]:
Case Style:
PCB-mountable
Case:
Termination Type:
Through-hole technology
Voltage Rating [V]:
63V
Number of Pins:
2
Tolerance [ % ]:
±20 %
External Diameter [mm]:
25 mm
External Height [mm]:
40 mm
Raster measure:
10 mm
ESR type:
No
Serienersatzwiderstand [Ohm/Hz/°C]:
90 mOhm @ 120Hz @ 20°C
Ripple Current max. [mA]:
2500 mA @ 120Hz @ 105°C
Endurance [h/°C]:
3.000h @ 105°C
Operating Temperature Min. [°C]:
-40 °C
Operating Temperature Max. [°C]:
+105 °C
ROHS:
Yes
pcs
Our Warehouse
57 pcs
Available for immediate delivery
Our Shop in Szeged
0 pcs
In Stock (or in 2 days from our warehouse the available quantity)
Package deals
Data
Weight:
25.76 g/pcs
