SA 23-12 SEKWA 57mm Anode Orange - KINGBRIGHT - SA23-12SEKWA
The picture is for illustration purposes only. Please read the product description!
Out of stock
7-Segment Display, 57mm Iv=190mcd, Common Anode L=601nm
Manufacturer code:
SA23-12SEKWA
Manufacturer:
Datasheet:
Group:
LED-displays
Component Family:
Case Style:
PCB-mountable
Case:
Termination Type:
Through-hole technology
Number of Pins:
10
Colour:
Orange
External Length [mm]:
70 mm
External Thickness [mm]:
12 mm
External Width [mm]:
48 mm
Dominant Wavelength [nm] :
601 nm
Character Size:
56.9 mm
Character Type:
1 x 7-segment, common anode
Luminous Intensity/Segment Iv [mCd @ mA]:
190 mCd @ 10 mA
Nyitóirányú feszültség/Segment Uf [V @ mA]:
8 V @ 10 mA
Forward Current If [mA], Nom.:
20 mA
Operating Temperature Min. [°C]:
-40 °C
Operating Temperature Max. [°C]:
+85 °C
ROHS:
Yes
Our Warehouse
0 pcs
Available for immediate delivery
Our Shop in Szeged
0 pcs
In Stock (or in 2 days from our warehouse the available quantity)
Package deals
Data
Additional Datasheet:
