Fuse Holder, Mountable Imax=16A 5x20mm or 6,3x32mm, requires bayonet insert (51-02-88/89)
Manufacturer code:
80000000105
Manufacturer:
Datasheet:
Group:
Fuse Holders - Other
Component Family:
Product Range:
Case:
Termination Type:
Solder tab
Number of Pins:
2
Standard:
UL
Continual Current [A], Max.:
16 A
Fuse Type:
5x20, 6.3x32 mm cylindrical
Voltage [V], Max.:
500 V
IP / NEMA Rating:
No
Contact Material:
Phosphor bronze
Contact Plating:
Tinned
Insulator Material:
Thermoplastic
Flammability Rating:
UL 94V-0
Operating Temperature Min. [°C]:
-25 °C
Operating Temperature Max. [°C]:
+70 °C
ROHS:
Yes
pcs
Quantity discount:
Quantity [pcs]
Net price [EUR]
Gross [EUR]
10
2,39 €
3,04 €
25
2,30 €
2,92 €
Our Warehouse
300 pcs
Available for immediate delivery
Our Shop in Szeged
0 pcs
In Stock (or in 2 days from our warehouse the available quantity)
Package deals
Customers also bought this
Data
Weight:
4.7 g/pcs
