TPN2R703NL, L1Q - 30V 45A 42W 3.3mOhm SMD TSON8 N-MOSFET - TOSHIBA
The picture is for illustration purposes only. Please read the product description!
Out of stock
MOSFET, 30V 45A 42W 3.3mOhm SMD TSON8
Manufacturer code:
TPN2R703NL,L1Q
Manufacturer:
Datasheet:
Group:
MOSFETs
Component Family:
Case Style:
Surface Mount (SMD)
Case:
Termination Type:
Surface mount (SMD)
Number of Pins:
8
Power Dissipation Ptot [W], Max:
42 W
Drain Current Id [A] @ 25°C:
45 A
On Resistance Rds[Ohm] @ Ids [A]:
0.0041 Ohm @ 22.5 A
Rise Time ton [nsec.]:
11.5 ns
Fall time toff [nsec.]:
24 ns
Gate Capacitance Ciss [pF]:
2100 pF
Drain-Source Voltage Uds [V]:
30 V
Operating Temperature Min. [°C]:
-55 °C
Operating Temperature Max. [°C]:
+150 °C
ROHS:
Yes
Our Warehouse
0 pcs
Available for immediate delivery
Our Shop in Szeged
0 pcs
In Stock (or in 2 days from our warehouse the available quantity)
Package deals
Data
Weight:
0.02 g/pcs
